China Manufacturer Customized 200L Fuel Storage Bladder 50 Gallon Fuel Tank_Oil Storage Bag_Products

China Manufacturer Customized 200L Fuel Storage Bladder 50 Gallon Fuel Tank

Oil Storage Bag

Product name : Fuel Storage Bladder

Material : PVC/TPU material

Capacity : 50L ~500,000Litres

Color : Green/blue/ black/yellow /gray

Application : Oil,Petrol and diesel storage bladder

Lifespan : 8-12years

inquiry

Tags:

Description

Product Description

Flexible and software Fuel Storage Flexitank Bladder is one kind of flexible fuel container, which is mainly used for temporary and long-term storage of gasoline, diesel, jet fuel, avgas, aviation kerosine,jetA1,and so on. Many customers use it for private jets, outdoor vehicles, ships, yachts, etc. Other expedition aircraft clubs and air force are like it too, and think it is awesome choice.

Capacity :20 L to 500,000 liters(All size we can accept customized )

Specification

Capacity ( litres/Goollon）	Size (length*width)	Material	Package	Weight
500L /130 Gallon	2*1m	0.9mm	0.06m3	5kg
1000L / 260 Gallon	2.5*1.5m	0.9mm	0.06m3	10kg
2000L/520Gallon	3*2m	0.9mm	0.06m3	15kg
3000L /790Gallon	3.5*2m	0.9mm	0.1m3	22kg
5000L/1320 Gallon	4.3*3m	0.9mm	0.13m3	35kg
10,000L/ 2640Gallon	5*4m	0.9mm	0.2m3	54kg
20,000L/5280Gallon	7*4.3m	1.0mm	0.3m3	86kg
30,000L/7920Gallon	7*7.3m	1.2mm	0.4m3	140kg
40,000L/10,000Gallon	9*7m	1.2mm	0.55m3	210kg
50,000L/13,200 Gallon	10*8m	1.2mm	0.8m3	260kg
60,000L/ 15,850Gallon	10*9m	1.2mm	0.9m3	320kg
100,000L/26,400Gallon	14*9m	1.2mm	1.0m3	480kg
200,000L/52,830Gallon	15*14m	1.3mm	1.8m3	702kg
300,000L/79,250Gallon	20*15m	1.3mm	2.5m3	980kg
500,000L/132,000Gallon	25*20m	1.5mm	6m3	1800kg
.....
Size accept Customized.

Fitting size reference :
1/2’’ - DN15	3/4’’ - DN20	1’’- DN25	1-1/4’’ - DN32	1-1/2’’ - DN40
2’’ - DN50	2-1/2’’ - DN65	3’’ - DN80	3-1/2’’ - DN90	4’’ - DN100
Material selection:Plastic, Stainless steel, Aluminum
